OKUMA ES-L10 CNC TURNING CENTER

Make: Okuma

Model No.: ES-L10

Year: 2005

Condition: Excellent

All specifications are approximations, and are subject to verification.

This machine is in very Good running condition. It is equipped With Big Bore Chuck, Tailstock & chip conveyor. On Our Floor fully powered / tested & is in Great working condition.

Okuma ES-L10 Equipped With:

12-Station Turret

OSP-U10L CNC Control

One Touch IGF Programming

Floppy Drive

Hydraulic Unit for chuck 10

Hydraulic Tailstock with Power Quill

Chip Pan and Chip Conveyor

Coolant System

Automatic Lubrication system

Foot Operated Control for Chuck and Tailstock

Okuma ES-L10 Specifications:

Max Turning Diameter: 12.20

Max Turning Length: 19.68

Max Bar Capacity: 3.05

Swing Over Bed: 21.65

Distance Between Centers: 24.6

Travel:

X Axis Travel: 8.10

Z Axis Travel: 20.47

Rapid Traverse X Axis: 787 IPM

Rapid Traverse Z Axis: 984 IPM

Spindle:

Spindle Nose: A2-8

Spindle Bore: 3.15

Spindle Speed: 30-3000 RPM

Spindle Motor: 20 HP

Turret:

Turret Capacity: 12 Stations

Turret Index Time: 0.5 Second

Tailstock:

Tailstock Body Travel: 14.3

Tailstock Quill Dia.: 3.54

Tailstock Quill Stroke: 3.93

Tailstock Taper: MT-5

General:

Power Source: AC 220 V, Three Phase, 60 Hz

Power Requirement: 68 Amps

Overall Dimensions: 110 x 68 x 80 High

Overall Dimensions: 140 x 68 x 80 High with Chip Conveyor

Weight : 8500 lbs Approx
