Make: OKUMA

Model No.: ESV-4020

OKUMA ESV-4020 Features:

OSP-U10M CNC Control

20 Automatic  tool changer

RS 232 Port

Floppy Drive

Rigid Tapping

Brush-type servo drive motors on all axis

Telescopic way covers

Flood Coolant system with Tanks

————————————————

Specifications:

Travels:

X-Axis: 40″

Y-Axis: 20″

Z-Axis: 20″

Rapid Traverse Rates: 941 Inch Per Minute

Cutting Feed Rates: 475 Inch Per Minute

Spindle Nose to Table (Min.- Max.): 6.1″ – 26.1″

Table:

Length: 47″

Width: 20″

Number of Std T-Slots: 3

T-Slot Width: 5/8″

Max Weight on Table: 1100 lbs

Spindle:

Taper Size: 40

Speed Range: 40 – 8,000 RPM

Spindle Power: 15 HP

Max Torque: 90ft-lb @ 2000RPM

Automatic Tool Changer:

Capacity: 20

Max Tool Weight: 13.2 lbs

Max Tool Dia: 5.90 ”

Max Tool Length: 12″

Tool Changing Time: 3.6 Seconds

General:

Air Required: 80 psi, 4 scfm

Power: 240v / 35 KVA / 3-Phase

Overall Dimensions: 150″ x 92″ x 99″ High

Weight: 11000 lbs
